Order quantity: 2
Payment method: T / T PayPal
Delivery time: ≤ 30 days
Product introduction:
1. It contains overheating protector. When the motor temperature reaches the rated value, it will automatically cut off the power to protect the motor.
2. The gear is protected by end cover, which is safer and more reliable.
3. The driver is composed of turbine and worm, which works stably.
4. Easy installation. In case of power failure, the door can be opened and closed manually after releasing the clutch.
model | LS-24-I | LS-24-II |
Power Supply | DC24V(120V/230V) | DC24V(120V/230V) |
power | 150W | 200W |
Maximum door weight | 300kg | 500kg |
Motor speed | 2200r/min | 2200r/min |
Gate speed | 16m/min | 16m/min |
Limit switch | Spring / magnetic (N.O. / N.C.) | Spring / magnetic (N.O. / N.C.) |
noise | ≤56Decibel | ≤56Decibel |
Noise operating temperature | -45ºC - +65ºC | -45ºC - +65ºC |
Degree of protection | IP44 | IP44 |
authentication | CCC,CE | CCC,CE |
Supply capacity | 6000 pieces / piece per month | |
Packaging details | Usually packed in cartons or pallets | |
Port | Shanghai / Ningbo | |
Delivery time | 15 days from the date of advance payment | |
Hangzhou Fuyang Taomen Gate Operators Co.,Ltd.
