Product introduction:
1. Integral oil immersed motor with waterproof and cooling performance.
2. It contains overheating protector. When the motor temperature reaches the rated value, it will automatically cut off the power to protect the motor.
3. The gear is protected by end cover, which is more safe and reliable.
4. The turbine and worm rotating mechanism can rotate stably.
5. It is easy to install. In case of power failure, the clutch can be opened and the door can be opened manually.
| technical parameter | ||||
| model | LSJJ-22 | LSJJ-35 | LSJJ-38 | LSJJ-45 |
| Power Supply | AC 230V 50Hz(AC 120V 60Hz) | AC 230V 50Hz(AC 120V 60Hz) | AC 230V 50Hz(AC 120V 60Hz) | AC 230V 50Hz(AC 120V 60Hz) |
| torque | 27N.m | 35N.m | 38N.m | 45N.m |
| Maximum door weight | 1000 KG | 1200 KG | 1500 KG | 2000 KG |
| motor speed | 1400r/min | 1400r/min | 1400r/min | 1400r/min |
| Gate speed | 12 m/min | 12 m/min | 12 m/min | 12 m/min |
| Limit switch | Spring / magnetic (N.O. / N.C.) | Spring / magnetic (N.O. / N.C.) | Spring / magnetic (N.O. / N.C.) | Spring / magnetic (N.O. / N.C.) |
| noise | ≤ 56 Decibel | ≤ 56 Decibel | ≤ 56 Decibel | ≤ 56 Decibel |
| working temperature | -40℃- +65℃ | -40℃- +65℃ | -40℃- +65℃ | -40℃- +65℃ |
| Degree of protection | IP44 | IP44 | IP44 | IP44 |
| authentication | CCC，CE | CCC，CE | CCC,CE | CCC,CE |
